Thuis /Producten/S de Cel van de Straallading/0.05%FS/10â „ ƒ LFS-35A Large Scale S Beam Truck Vehicle Load Cell Compression and Tension Force Sensor

0.05%FS/10â „ ƒ LFS-35A Large Scale S Beam Truck Vehicle Load Cell Compression and Tension Force Sensor

1 Piece
MOQ
$100.00(1 - 9 Pieces) $96.00(10 - 99 Pieces) $92.00(>=100 Pieces)
Prijs
0.05%FS/10â „ ƒ LFS-35A Large Scale S Beam Truck Vehicle Load Cell Compression and Tension Force Sensor
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Model Number: LFS-35A
Type: ABSOLUTE PRESSURE SENSOR
Usage: Weighing
Theory: 1
Output: 1
Description: Ligent
capacity: 0-5-100kg
material: Stainless Steel
accuracy: 0.1%FS
zero balance: ±2%FS
creep: 0.05%FS
Temp effect on output: 0.05%FS/10℃
Impedance: 350Ω
Insulation: ≥5000MΩ/100VDC
maximum overload: 500%
cable specification: D3x3m
Basis informatie
Model Number: LFS-35A
Betalen & Verzenden Algemene voorwaarden
Packaging Details: Foam inside and carton outside/ Customize
Supply Ability: 600 Piece/Pieces per Month
Productomschrijving
LFS-35A Large Weighing Scale S Beam Truck Vehicle Load Cell Compression And Tension Force Sensor
Features:

1. The S type force sensor with high accuracy. They have non-linearity of 0.05%.
2. The force sensors are small and it is easy to install them.
3. These force sensors have high responsive speed.
4. These force sensors utilize strain gauge technology.

Applications:
Miniature S Type Force Sensors are mainly applied in tension and pressure testing instruments and automatic equipments fields,
such as insertion force test instrument, riveting machine, welding machine, hot&cold lamination machine, feeling tester for
keyboard switch, and etc.
Capacity
0-5,10,20,30,50,100kg
Total Accuracy
0.1% F.S.
Material
Stainless steel
Rated output
2.0±10% mV / V
Zero balance
± 2 % F.S.
Non-linearity
0.05% F.S.
Hysteresis
0.05% F.S.
Repeatability
0.05% F.S.
Creep (30min)
0.05% F.S.
Temp. effect on output
0.05% F.S. / 10ºC
Temp. effect on zero
0.05% F.S. / 10ºC
Impedance
350±10Ω/350±3Ω
Insulation
≥5000MΩ/100VDC
Recommended excitation voltage
5-10V
Compensation temp range
- 10 ~ 60 ºC
Operation temp range
- 20 ~ 80ºC
Safe overload
Compression 200% Tension 150%
Maximum overload
Compression 500% Tension 200%
Cable size
Ø3×3000 mm
Responsive speed frequency
1200HZ
TEDS
TEDS available
Wiring
Red: + Excitation Black: - Excitation
Green: + Signal White: - Signal
Product Name: 0-5-100kg LFS-35A stainless steel S type compression and tension force sensor
Model No: LFS-35A
Shenzhen Ligent Sensor Tech Co., Ltd. is a national high-tech enterprise specializing in force measurement technology research and product development, production, sales and services, mainly engaged in the R&D and production of sensors, transmitters and control instrument, and providing solutions for engineering control system. We have modern spacious factory buildings, advanced production and testing equipment, professional R&D teams and management system. Also, we have now achieved ISO9001 quality management system certification and a number of ROHS and CE product certifications.
With more than 30 years of advanced technology and experiences in the field of force measurement, we have designed and produced more than hundreds of types of products including miniature compression and/or tension load cells, multi-dimensional force sensors, force sensors, pressure transducers, transmitters/amplifiersand control indicators, which have obtained a number of national patents. Our products are widely applied in a variety of new and intelligent high-end areas, such as industrial automation production lines, robotics, new energy, metallurgy and medical apparatus and instruments. Through continuous improvement, our products are able to replace foreign similar products due to their high stability and sensitivity.
Our mission statement: to provide the most ‘powerful’ services and the most ‘accurate’ products for intelligent manufacturing enterprises, in order to become one of top force measurement brand in the field of automation and intelligent manufacturing.
Business philosophy: to create a win-win situation with customers, share with employees, and assist in the development of automation in china.
Q: WHAT IS THE MOQ?
A: If we don’t have it in stock, the MOQ is 10 pcs
---------------------------------------------------------------------------------------------------------
Q: WHAT IS LEAD TIME?
A: If we have it in stock, we can ship it to you within about 3-5 working days. If we don’t have it in stock, the lead time will be 2-4 weeks.
---------------------------------------------------------------------------------------------------------
Q: WHAT IS THE PAYMENT TERMS?
A: T/T, Western Union, L/C, Escrow alibaba is acceptable.
---------------------------------------------------------------------------------------------------------
Q: WHAT IS THE EXPRESS DELIVERY?
A: DHL, Fedex, TNT ,EMS, UPS etc. We will choose the safe and cheapest way for you to reduce your cost. Economic shipping way: by sea, by air transport If you place mass order with us, the shipping way of by sea or by air transport will be ideal choice.
---------------------------------------------------------------------------------------------------------
Q: WHAT IS THE QUAITY GUARANTEE?
A: Quality guarantee: 12 months. If the product has quality problem within 12 months,if there is quality problem which cuased by our side, you can send back goods for repair and pay the freight cost at your side. or we can send replacement.
---------------------------------------------------------------------------------------------------------
Q: IS THERE ANY AFTER-SALE SERVICE?
A: After you receive our product, if you have any questions or need any assistance, we can provide you the after-sale service by e-mail,skype,trade manager,telephone and QQ etc.
